HOBO MX1102A CO2 Monitor & Data Logger - Optional Remote Monitoring
- Low stock - 10 items left
The Onset HOBO MX1102A CO2 monitor & data logger makes it even easier to monitor and record carbon dioxide levels in buildings and other non-condensing environments. The highly-accurate NDIR CO2 sensor measures CO2 from 0–5,000 parts per million (ppm).
Access your data wirelessly from your smartphone, tablet or Windows computer within a 100-foot range.
Communications
Access your data directly from your mobile phone, tablet or Windows computer when within 100 foot (30 m) line-of-sight range of the logger, with the free HOBOconnect app.
To enable cloud data storage and analysis, add an MX Data Plan (select from the options above).
To enable near real-time remote monitoring and alerts via email or text message, add an MX Data Plan and an MX Gateway (select from the options above). Note: the MX Gateway must be indoors.
You can download the HOBOconnect app here:
| Power | Battery only |
|---|---|
| HOBO Product Series | MX1100 |
| Measurements | Air Quality, CO2, Dew Point, Humidity, Temperature |
| Data Available By | Display, USB, Online, Mobile App, WiFi, Email, Wireless (Bluetooth/RF) |
To see the full specifications for this product, please see the User Manual under the Resources tab.
|
CO2 Sensor |
|
|
Range |
0 to 5,000 ppm |
|
Accuracy |
±50 ppm ±5% of reading at 25°C (77°F), less than 70% RH and 1,013 mbar |
|
Warm-up Time |
15 seconds |
|
Calibration |
Auto or manual to 400 ppm |
|
Non-linearity |
<1% of FS |
|
Pressure Dependence |
0.13% of reading per mm Hg (corrected via user input for elevation/altitude) |
|
Operating Pressure Range |
950 to 1,050 mbar (use Altitude Compensation for outside of this range) |
|
Compensated Pressure Range |
-305 to 5,486 m (-1,000 to 18,000 ft) |
|
Sensing Method |
Non-dispersive infrared (NDIR) absorption |
|
Temperature Sensor |
|
|
Range |
0° to 50°C (32° to 122°F) |
|
Accuracy |
±0.21°C from 0° to 50°C (±0.38°F from 32° to 122°F) |
|
Resolution |
0.024°C at 25°C (0.04°F at 77°F) |
|
Drift |
<0.1°C (0.18°F) per year |
|
RH Sensor |
|
|
Range |
1% to 90% RH (non-condensing) |
|
Accuracy |
±2% from 20% to 80% typical to a maximum of ±4.5% including hysteresis at 25°C (77°F); below 20% and above 80% ±6% typical |
|
Resolution |
0.01% |
|
Drift |
<1% per year typical |
|
Response Time |
|
|
Temperature |
12minutes to 90% in airflow of 1 m/s (2.2 mph) |
|
RH |
1 minute to 90% in airflow of 1 m/s (2.2 mph) |
|
CO2 |
1 minute to 90% in airflow of 1 m/s (2.2 mph) |
|
Logger |
|
|
Radio Power |
1 mW (0 dBm) |
|
Transmission Range |
Approximately 30.5 m (100 ft) line-of-sight |
|
Wireless Data Standard |
Bluetooth Smart (Bluetooth Low Energy, Bluetooth 4.0) |
|
Logger Operating Range |
0° to 50°C (32° to 122°F); 0 to 95% RH (non-condensing) |
|
Logging Rate |
1 second to 18 hours |
|
Logging Modes |
Fixed interval (normal, statistics) or burst |
|
Memory Modes |
Wrap when full or stop when full |
|
Start Modes |
Immediate, push button, date & time, or next interval |
|
Stop Modes |
When memory full, push button, date & time, or after a set logging period |
|
Time Accuracy |
± 1 minute per month at 25°C (77°F) |
|
Power Source |
4 AA 1.5 Volt batteries (user replaceable) or USB power source (5 V DC, 2 Watts) |
|
Battery Life |
6 months, typical with logging and sampling intervals of 5 minutes or slower; 6 months or less with logging and sampling intervals faster than 5 minutes while logging CO2. Entering burst logging mode will impact battery life. With HOBOconnect use, battery life can be reduced by remaining connected, excessive readouts, checking of Full Status Details, audible alarms, and paging. Visual/audible alarms and other events can have a marginal impact on battery life. |
|
Memory |
128 KB (84,650 measurements, maximum) |
|
Download Type |
USB 2.0 interface or via Bluetooth Smart |
|
Full Memory Download Time |
20 seconds via USB; approximately 60 seconds via Bluetooth Smart, may take longer the further the device is from the logger |
|
LCD |
LCD is visible from 0° to 50°C (32° to 122°F); the LCD may react slowly or go blank in temperatures outside this range |
|
Size |
7.62 x 12.95 x 4.78 cm (3.0 x 5.1 x 1.88 inches) |
|
Weight |
267.4 g (9.43 oz) |
|
Environmental Rating |
IP50 |
The CE Marking identifies this product as complying with all relevant directives in the European Union (EU).
- HOBO MX1102 CO2 Monitor & Data Logger
- Four x AA 1.5 V alkaline batteries
This item is priced on application. Tell us what you need and we'll send you a quote.
Or call us on 01243 558270
Buying in Volume, or Just Want Some Helpful Advice?
Call +44 (0)1243 558270, or fill out our contact form.
Access your data directly from your mobile phone, tablet, or Windows computer when within 100 foot line-of-sight range of the logger - with the free HOBOconnect app.
To enable cloud data storage and analysis - add an MX Data Plan (select from options above).
To enable near real-time remote monitoring and alerts via email/text message - add an MX Data Plan and MX Gateway (select options above).
Also features a USB port so it can be used with a computer running HOBOware graphing & analysis software.
Key Features
- Self-calibrating NDIR CO2 sensor technology ensures optimal accuracy and lower maintenance costs
- Wireless communication via Bluetooth technology
- Six-month battery life at 5-minute CO2 logging rate
- Easy to deploy and offload using free HOBOconnect app
- Visual and audible high & low alarm thresholds
- Also monitors temperature & humidity
- Patented connectivity technology
- Optional cloud data access and remote monitoring/alerts.
Requires a compatible mobile device or Windows computer and the HOBOconnect app.
Tracking CO2 is a critical aspect of measuring indoor air quality and ensuring a healthy environment. Whether you need to monitor an office space, school, or hospital; the HOBO MX1102 makes the process easy, and cost-effective. The HOBO MX1102A is also an ideal choice for UK housing associations needing to carry out passive house audits/monitoring of CO2.
Environment: The MX1102A Data Logger is for use in Indoor environments
Measurements: The MX1102A Data Logger supports the following measurements: Carbon Dioxide, Dew Point, Relative Humidity and Temperature
